High-Speed Dividing Pulse Relay

DPR-1

The SSI DPR-1 High-Speed Dividing Pulse Relay is designed specifically for water and gas meter pulse applications, supporting input rates up to 200 pulses per second. It provides two sets of isolated dry 2-wire Form A contacts from a single Form A input, with the output divided by a user-selected ratio ranging from 2 to 4096. Division ratio selection is made with a single jumper shunt on the relay board — no tools required beyond a set of needle-nose pliers.

The DPR-1 counts input pulses for division only when a valid pulse sequence is detected, ensuring a high degree of noise rejection in demanding field environments. Both outputs are independently fused, and built-in MOV transient protection eliminates the need for external suppressors. The DPR-1 is housed in a polycarbonate enclosure suitable for mounting inside a customer-supplied enclosure appropriate for the application.

Request Price Quote Download Data Sheet
Instructions
The DPR-1 High-Speed Dividing Pulse Relay on a white background

Product Highlights

The DPR-1’s jumper-selectable division ratio makes it straightforward to configure for a wide range of metering scenarios — from simple 2:1 divisions to ratios as high as 4096:1 — all without software or programming tools. The relay is well suited for applications where fast-pulsing meters (such as water or gas flow meters) need their output rate reduced before feeding downstream recording or SCADA equipment.

Both outputs use solid-state dry contacts rated at 250VAC/VDC at 100mA, with 2500Vrms input/output isolation. Bright yellow and green LEDs provide instant visual confirmation of input and output status, and the Euro-type terminal strips ensure safe, reliable field wiring.

Features

The SSI DPR-1 high-speed dividing pulse relay delivers two isolated Form A outputs from a single input with jumper-selectable division ratios from 2 to 4096.
  • Up to 200 pulses per second — designed specifically for high-speed water and gas meter pulse applications.
  • Jumper-selectable division ratio — user-adjustable from 2 to 4096 via a single onboard jumper shunt; no tools required.
  • Two isolated Form A outputs — dual dry 2-wire KY contacts rated at 250VAC/VDC, 100mA, factory fused at 1/10A.
  • Sequence validation — counts input pulses for division only on valid pulse sequences, providing strong noise rejection.
  • +13VDC pulled-up sense voltage — supplied on the Y input terminal, compatible with mechanical contacts, NPN open-collector, or FET pulse initiators.
  • Built-in MOV transient protection — eliminates the need for external off-board transient suppressors.
  • Yellow and green LED indicators — display input and output status at all times for rapid visual system check.
